Article: Slps 465

Bogie flat wagon with four wheelsets. They are equipped with relocatable end stanchions and lateral swivel stanchions. The wagons are intended for transporting sleepers and track skeletons. These wagons do not have rails for gantry cranes.

Technical details

Average tare weight (kg)

22,700

Maximum speed (km/h)

100

Smallest radius of curvature (m)

75

Largest wagon width (mm)

2,940

Between the swivel stanchions (mm)

2,400

Loading length (mm)

20,100

Loading length between end faces (mm)

19,430 or 14,848

Brake type

KE-GP

Number of brake cylinders (pcs.)

1

Brake cylinder diameter (mm)

406

Distributor valve type

KE 1aSL

Type of load-proportional braking

Two-stage, mechanical, to be changed over manually

Buffer type
- End force (kN)
- Stroke (mm)

UIC 526-1, Category A
590
105

Buffer head dimensions (mm)

450 x 340

Automatic coupler

Prepared

First year of delivery or year of construction of the oldest wagons at this time

1978

Load limits

A

B

C

S

41.0 t

49.0 t

57.0 t


Additional information:

Slps 465 wagons evolved from type 248 service wagons. They are equipped with relocatable end stanchions and lateral swivel stanchions. The wagons are intended for transporting sleepers and track skeletons. These wagons do not have rails for gantry cranes.
